Description
► 40W, 50W CO2 Laser Type
► 1120mm Max Width Available
► Portable, Desktop, Inexpensive for Home or Small business
► Engraving or Cutting Wood, Leather, Paper, Stickers, Felt, Cloth, Acrylic, Plastic, Rubber and so on
► CE, ISO, FDA Certification
► English User Manual and Video to how to operation
► Saving Time, Saving Labor Cost, Saving your Money
► 1120mm Max Width Available
► Portable, Desktop, Inexpensive for Home or Small business
► Engraving or Cutting Wood, Leather, Paper, Stickers, Felt, Cloth, Acrylic, Plastic, Rubber and so on
► CE, ISO, FDA Certification
► English User Manual and Video to how to operation
► Saving Time, Saving Labor Cost, Saving your Money
Specification
| Model | M-980 | M-1220 | M-1570 |
|---|---|---|---|
| Material made | Professional designed stand type metal frame | ||
| Max. feeding width | 980mm | 1380mm | 1730mm |
| Max. cutting width | 820mm | 1220mm | 1570mm |
| Driving type | Vertical roller driving type | ||
| Driving motor | Stepping motor | ||
| PC interface | RS232 serial port or USB | ||
| Laser head | Designed by MOMO | ||
| Laser mode | hollow, engraving, cutting, drawing | ||
| Knife | Internal rotary style (Roland© standard type blade) | ||
| Knife mode | Same as a general cutting plotter | ||
| Plotting pen | Standard water based ball point pen refill | ||
| Plotting mode | Same as a general cutting plotter | ||
| Power supply | AC220V/110V ±5%, 50Hz-60Hz | ||
| Total power | 50W ~ 200W (depending on mode of operation) | ||
| Laser tube power | 40W | ||
| Cutting speed | Min.10mm/S ~ Max. 800mm/S | ||
| Cutting pressure | Min. 10g ~ Max. 500g（Knife mode） | ||
| Resolution | 0.0254mm/step | ||
| Repeat accuracy | 0.0127mm | ||
| Language format | DM/PL compatible | ||
| Baud rate | 38.4K | ||
| Data transmission | 8 data bits, 0 parity bit, 1 stop bit | ||
| Water-load protection (laser) | yes | ||
| Uncover protection (laser) | No | ||
| Working environment | 5-40℃, 5-90% R.H. (without condensate) Keep away from the environment with dust or high electromagnetic interference | ||
| Control panel | LCD display + key + switch + test + current regulation + current indication | ||
| Min. character | Chinese character: 3mm; letter: 2mm; (varies depending on character font and media) | ||
| Laser current range | 0-20mA | ||
| Interface type | Serial port/USB | ||
| Machine net weight | 46.5KG | 51KG | 61KG |
| Net weight of water pump and air pump | 2.5KG | ||
| Weight of wooden case and accessories | 21KG | 31.5KG | 36.5KG |
Package size |
1570mm*535mm*490mm export package (plywood case package) |
1970mm*535mm*490mm export package (plywood case package) |
2320mm*535mm*490mm export package (plywood case package) |
| Packed weight | 70kg (including standard configuration and wooden case) |
85kg (including standard configuration and wooden case) |
100kg (including standard configuration and wooden case) |
| Machine dimensions | 1420mm*700mm*1120mm | 1820mm*700mm*1120mm | 2170mm*700mm*1120mm |
| Applicable material | Soft and thin nonmetal material, such as paperboard, cutting vinyl | ||
| Application range | Currently, this machine has been widely used for apparel, label, outdoor signs, lamp-box, screen printing, car decoration, etc. | ||
| Remarks: | When the power is 110V，the weight is 2kg increased. | ||
Video
What Can You Do
What can you do with a MOMO Laser cutter plotter machine:
MOMO Laser Cutter support engrave or cut most of Non-metal material , like Wood, Leather, Paper, Stickers, Felt, Cloth, Acrylic, Plastic, Rubber and so on.
MOMO Laser Cutter support engrave or cut most of Non-metal material , like Wood, Leather, Paper, Stickers, Felt, Cloth, Acrylic, Plastic, Rubber and so on.
| Material | Thickness |
| Leather | 1 mm |
| Paper | 0.5-1.5 mm |
| Felt | 2-3 mm |
| Wood | 3 mm |
| Rubber | 3 mm |
